Italian Flue Ornamental 20in
£1,016.40 – £1,071.60
Designed by the American Radiator Company in the late 1890s, the Italian Flue Ornamental combined the single-column form typical of hospital radiators with highly decorative detailing, making it a rare blend of form and function.
Premium branded paint finishes from Little Greene and Farrow & Ball are available on request. Please contact our Sales Team for more information.
Technical Data
Model Specifications
| Attribute | Value |
|---|---|
| Exponent, n | 1.25 |
| Factor, Km | 0.64 |
| Height With Legs (mm) | 508 |
| Height Without Legs (mm) | 457 |
| Bottom Inlet To Floor (mm) | 114 |
| Max Section Depth (mm) | 216 |
| Mid Section Depth (mm) | 216 |
| Output (ΔT50, W) | 85 |
| Output (ΔT30, W) | 44 |
| Interaxis Distance (mm) | 344 |
| Section Length (mm) | 76 |
| Internal Volume (L) | 1.7 |
| Empty Leg Section Weight (kg) | 11.43 |
| Empty Mid Section Weight (kg) | 10.3 |
| Casting Origin | Chicago, USA |
| Heating Medium | Hydronic, One-pipe steam, Two-pipe steam |
| Construction Types | Threaded nipples |
| Connection Options | BBOE, TBOE, TBSE |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| ORC-ARC-IFO-20-4 | 4 | 334 | 340 | 176 | 1 | £0.00 |
| ORC-ARC-IFO-20-6 | 6 | 486 | 510 | 264 | 1 | £0.00 |
