Sunbeam 41in
£1,722.00
Produced by Longden & Co. in Sheffield from the late 1800s, the Sunbeam was the most popular cast iron radiator for churches, featuring a distinctive design which soon became associated with churches and chapels.
Premium branded paint finishes from Little Greene and Farrow & Ball are available on request. Please contact our Sales Team for more information.
Technical Data
Model Specifications
| Attribute | Value |
|---|---|
| Exponent, n | 1.25 |
| Factor, Km | 0.96 |
| Height With Legs (mm) | 1041 |
| Height Without Legs (mm) | 1041 |
| Bottom Inlet To Floor (mm) | 32 |
| Max Section Depth (mm) | 102 |
| Mid Section Depth (mm) | 102 |
| Output (ΔT50, W) | 127 |
| Output (ΔT30, W) | 65 |
| Interaxis Distance (mm) | 0 |
| Section Length (mm) | 76 |
| Internal Volume (L) | 0.68 |
| Empty Leg Section Weight (kg) | 4.8 |
| Empty Mid Section Weight (kg) | 4.8 |
| Casting Origin | Sheffield, England |
| Heating Medium | Hydronic, One-pipe steam, Two-pipe steam |
| Construction Types | Manifold bottom |
| Connection Options | BBOE |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| ORC-LAC-S-41-15 | 15 | 1170 | 1905 | 975 | 1 | £0.00 |
