Neo Classic 4 Column 24in
£667.20 – £1,299.60
Manufactured by Ideal Standard in Hull, England, from 1930 to the early 1970s. This under-window radiator was part of the Neo Classic range that form the most widespread vintage cast iron radiators in Britain.
Premium branded paint finishes from Little Greene and Farrow & Ball are available on request. Please contact our Sales Team for more information.
Technical Data
Model Specifications
| Attribute | Value |
|---|---|
| Exponent, n | 1.2541 |
| Factor, Km | 0.5699 |
| Height With Legs (mm) | 610 |
| Height Without Legs (mm) | 560 |
| Bottom Inlet To Floor (mm) | 79 |
| Max Section Depth (mm) | 143 |
| Mid Section Depth (mm) | 143 |
| Output (ΔT50, W) | 77 |
| Output (ΔT30, W) | 40 |
| Interaxis Distance (mm) | 500 |
| Section Length (mm) | 51 |
| Internal Volume (L) | 0.7 |
| Empty Leg Section Weight (kg) | 5.5 |
| Empty Mid Section Weight (kg) | 4.8 |
| Casting Origin | Hull, England |
| Heating Medium | Hydronic, One-pipe steam, Two-pipe steam |
| Construction Types | Threaded nipples |
| Connection Options | BBOE, TBOE, TBSE |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| ORC-IS-NC-4C24-3 | 3 | 183 | 231 | 120 | 1 | £0.00 |
| ORC-IS-NC-4C24-7 | 7 | 387 | 539 | 280 | 1 | £0.00 |
| ORC-IS-NC-4C24-8 | 8 | 438 | 616 | 320 | 1 | £0.00 |
| ORC-IS-NC-4C24-9 | 9 | 489 | 693 | 360 | 1 | £0.00 |
| ORC-IS-NC-4C24-10 | 10 | 540 | 770 | 400 | 1 | £0.00 |
| ORC-IS-NC-4C24-11 | 11 | 591 | 847 | 440 | 1 | £0.00 |
| ORC-IS-NC-4C24-12 | 12 | 642 | 924 | 480 | 1 | £0.00 |
| ORC-IS-NC-4C24-13 | 13 | 693 | 1001 | 520 | 1 | £0.00 |
| ORC-IS-NC-4C24-14 | 14 | 744 | 1078 | 560 | 1 | £0.00 |
| ORC-IS-NC-4C24-15 | 15 | 795 | 1155 | 600 | 1 | £0.00 |
| ORC-IS-NC-4C24-16 | 16 | 846 | 1232 | 640 | 1 | £0.00 |
| ORC-IS-NC-4C24-17 | 17 | 897 | 1309 | 680 | 1 | £0.00 |
| ORC-IS-NC-4C24-18 | 18 | 948 | 1386 | 720 | 1 | £0.00 |
| ORC-IS-NC-4C24-20 | 20 | 1050 | 1540 | 800 | 1 | £0.00 |
| ORC-IS-NC-4C24-22 | 22 | 1152 | 1694 | 880 | 1 | £0.00 |
| ORC-IS-NC-4C24-25 | 25 | 1305 | 1925 | 1000 | 1 | £0.00 |
| ORC-IS-NC-4C24-27 | 27 | 1407 | 2079 | 1080 | 1 | £0.00 |
| ORC-IS-NC-4C24-34 | 34 | 1764 | 2618 | 1360 | 1 | £0.00 |
