Princess 2 Column 30in
£1,125.60 – £1,417.20
One of Britain’s most iconic school radiators, the Princess was manufactured in Nottingham from the early 1900s. It became a familiar fixture in schools and libraries across the country until its discontinuation in the 1930s.
Premium branded paint finishes from Little Greene and Farrow & Ball are available on request. Please contact our Sales Team for more information.
Technical Data
Model Specifications
| Attribute | Value |
|---|---|
| Exponent, n | 1.2271 |
| Factor, Km | 0.91 |
| Height With Legs (mm) | 762 |
| Height Without Legs (mm) | 711 |
| Bottom Inlet To Floor (mm) | 102 |
| Max Section Depth (mm) | 190 |
| Mid Section Depth (mm) | 190 |
| Output (ΔT50, W) | 110 |
| Output (ΔT30, W) | 57 |
| Interaxis Distance (mm) | 616 |
| Section Length (mm) | 76 |
| Internal Volume (L) | 2.2 |
| Empty Leg Section Weight (kg) | 8.8 |
| Empty Mid Section Weight (kg) | 7.92 |
| Casting Origin | Nottingham, England |
| Heating Medium | Hydronic, One-pipe steam, Two-pipe steam |
| Construction Types | Threaded nipples |
| Connection Options | BBOE, TBOE, TBSE |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| ORC-B-P2C30-4 | 4 | 334 | 440 | 228 | 1 | £0.00 |
| ORC-B-P2C30-5 | 5 | 410 | 550 | 285 | 1 | £0.00 |
| ORC-B-P2C30-6 | 6 | 486 | 660 | 342 | 1 | £0.00 |
| ORC-B-P2C30-8 | 8 | 638 | 880 | 456 | 1 | £0.00 |
| ORC-B-P2C30-9 | 9 | 714 | 990 | 513 | 1 | £0.00 |
| ORC-B-P2C30-10 | 10 | 790 | 1100 | 570 | 1 | £0.00 |
| ORC-B-P2C30-12 | 12 | 942 | 1320 | 684 | 1 | £0.00 |
| ORC-B-P2C30-13 | 13 | 1018 | 1430 | 741 | 1 | £0.00 |
